01
Camera assessment and root severity rating
We push a drain camera through the full lateral length. Entry points — typically bell-and-spigot joints at 5-foot intervals in clay tile — are mapped and rated using PACP (Pipeline Assessment Certification Program) root density criteria: light (root tails only), moderate (root mass covering 25–50%), severe (mass over 50% or structural displacement). This tells us which cutting head size, how many cutting passes, and whether the pipe can safely handle hydro jetting pressure before we start any work.
02
Mechanical cutting pass
The licensed technician runs a spiral root cutter or chain flail sized to the pipe bore — typically 4-inch for residential laterals — on multiple passes until the cable feeds freely through the full run. We do not stop at the first pass. Each cutting pass reduces root mass density and opens the bore for the jetting head. For severe root balls, a root saw attachment may be used first to break up the compacted mass before the spiral cutter is run.
03
Hydro jet scour
After the cutting passes clear bulk mass, we run the hydro jetting hose with a 360-degree rotating nozzle at 4,000 PSI. The jet scours fibrous root material and root hair mats from the pipe wall, flushes the cut root mass downstream to the city main, and leaves the pipe interior clean enough for foaming herbicide to bond to bare clay or cast iron surface. The jetting pass also confirms pipe integrity — a cracked tile section shows water loss in the trench.
04
Camera verification
A post-treatment camera pass confirms the pipe interior is clear and re-rates any remaining root material. We document the entry joint locations and their current condition — open mortar joint, offset joint, hairline crack — and photograph the cleared pipe. If structural damage is found, we provide an on-site assessment of whether foaming maintenance or CIPP lining is the appropriate long-term path.
05
Root foaming herbicide application
With the pipe confirmed clean, we introduce RootX foam or a Dichlobenil-based foaming root killer through the cleanout. The foam generates in the pipe and expands to coat the full pipe cross-section including every joint gap — the exact spots where root tips are anchored in the surrounding soil. Contact time is 60 minutes minimum before flushing. We provide documentation of the product used and the application date for your maintenance records.
06
Lining recommendation if structural damage is found
If the post-job camera reveals offset joints, cracked clay tile sections, or a collapsed Orangeburg section, we provide a written CIPP lining estimate before leaving. Foaming herbicide on a structurally compromised pipe buys 12–18 months at best — the open joint will continue admitting root tips faster than the herbicide suppresses them. A CIPP liner installs inside the existing pipe, seals every bell-and-spigot joint permanently, and eliminates root entry with no excavation required. See our sewer line repair page for lining details.
